IMPROVE 10~30kWh Stackable Power Storage Brick

Nominal Voltage51.2V
Nominal Capacity200Ah
Nominal Energy10.24kWh
Warranty5 Years
OEM/ODMWarmly Welcomed
You may like this
5~30kWh Stackable Power Storage Brick | IMPROVE BATTERYStackable High Voltage Energy Storage System | IMPROVE BATTERY

51.2V IMPROVE Stackable Power Storage Brick

Enables efficient energy management

5000W Inverter and battery integrated stacked home energy storage power supply
Inverter has an American standard and European standard to choose from
Provide efficient and reliable power supply to residential properties
Single module is 51.2V 200Ah 10240Wh can be freely combined 10KWH  20KWH  30KWH

51.2V IMP Stackable Power Storage Brick Series design enables users to scale up the storage capacity according to your specific requirements. enabling it to drive almost all appliances as a reliable backup power in temporary events and construction sites, off-grid living, and more.



IMPROVE stackable energy storage systemLiFePO4 Battery BMSinstallation batterysolar system connectionRS232/RS485/CANbluetooth batterymaintenance-free

IMPROVE BATTERY COMPANYIMPROVE BATTERY factory overviewIMPROVE BATTERY exported overseas all over the worldIMPROVE BATTERY partnersIMPROVE BATTERY certifications
Datasheet Specification
Battery Modules 51.2V 200Ah 10240Wh
Number of Modules 1 2 3
Nominal Energy 10.24kWh 20.48kWh 30.72kWh
Dimension (L * W * H) 600*500*619mm 600*500*952mm 600*500*1285mm
Approx. Weight 140Kg 240Kg 340Kg
Life Cycles ≥6000 Cycles (80%DOD), at 25°C
Communication Mod RS232 / RS485 / CAN
Inverter 110Vac 230Vac
Inverter Output
Rated Output Power
5000W
Rated Output Voltage
120Vac (L/N/PE single-phase)
230Vac (L/N/PE single-phase)
Rated AC Frequency
50 / 60Hz
Waveform
Pure sine wave
Switch Time
10ms
Parallel Capacity 1-6 units (single/three phase)
PV Input
Number of MPP Trackers 1
Max. PV Array Power 5500W
Max. Input Current 22A
Max. Voltage of Open Circuit 500Vdc
MPPT Voltage Range 125-450CVdc
Mains / Generator Input
Input Voltage Range
90~140Vac
90~280Vac
Frequency Range
50Hz / 60Hz
Bypass Overload Current
60A 40A
Efficiency
MPPT Tracking Efficiency 99.9%
Max. Battery Inverter Efficiency 92%
Battery
Battert Type LiFePO4
Rated Battery Voltage
48Vdc / 51.2Vdc
Voltage Range
37.5V-54.5V / 40V-58.4V
Max. MPPT Charging Current 100A

Max. Mains / Generator
Charging Current

40A 60A
Max. Hybrid Charging Current 100A
Operating Temperature
Charging: 0°C ~ +45°C / Discharge: -20°C ~ +55°C
Storage Temperature
-10°C ~ +45°C
